Comprehensive Guide to Tinplate Aerosol Can Packaging Dimensions

Tinplate aerosol cans are primarily classified by their body diameter (in millimeters). Common diameters include 45mm, 52mm, 57mm, 60mm, 65mm and 70mm.

Height and capacity can be customized as needed to meet the specific packaging requirements of various products.

Selection and Customization Basics: Shoulder Structure (Necked-in vs. Straight-body) ：

Necked-in Can: Features a tapered top opening and is typically designed to accommodate a 1-inch valve (approximately 25.4mm in diameter)—a standard configuration for products such as most spray paints and insecticides.

Straight-body Can: Features a cylindrical, straight body; this style is frequently used for products requiring specific capacities or those utilizing specialized spray nozzles.

Capacity and Fill Rate: The actual fill volume of an aerosol can typically ranges from 75% to 85% of the container's total capacity. Headspace must be reserved at the top to accommodate the propellant (such as compressed gas or liquefied gas), thereby ensuring a safe pressure margin within the can.

Printing and Surface Treatment: The exterior surface of the tinplate can be customized with various printing techniques (e.g., four-color process or spot color printing). The interior wall can be coated with epoxy resin or rust-inhibiting oil, depending on the acidity or alkalinity of the product contents.

These aerosol cans are widely utilized for packaging a diverse range of products, mainly used for the packaging : insect killer, air freshener, shaving foam, body spray, hair spray furniture polishing, spraypaint, cleaner and poly foam, etc.

Main applications industry: automobile care products, daily chemicals, personal care, chemical products and other fields.

The common parameters for aerosol cans—including diameter, height, and corresponding dome height—are as follows:

Table of Common Aerosol Can Sizes and Specifications：

If you need custom aerosol cans, you can choose Huate.

Huate has nearly 41 years experience of aerosol cans making and R&D. has more than 20 years experience of export foraerosol can, the customers are from more than 30 countries and regions around the world . It has an outstandingprofessional group to provide customer good quality and attentive service.

Huate, with professional knowledge and understanding of international standards of aerosol can, has successfullydeveloped a series of aerosol cans specifications that are suitable for USA. and European markets. All products had gotthe certificate by the .S and European organization. In 2009, Huate had got the DOT certification issued by the U.S.Department of Transportation.

It would be even better if you could provide sample images. Feel free to send us pictures when requesting a quote.
